316L Stainless Steel Floor Plate, Checker Plate, Chequered Plate
AISI / ASTM / UNS 316L, EURONORM 1.4404, Nom. X2CrNiMo17-12-2
Production Standard: ASTM-A-240/A793, ASME-SA-240/SA793,
TIASCO is one of the few service centres that stocks 316/316L EN1.4404 stainless diamond and tear-drop plate along with the more common 304/304L stainless steel floor plate. We offer a full range of pattern sizes that can ship for immediate delivery. Alternatively, we can custom level stainless checker and floor plate coil to your exact length, reducing yield loss, handling and delivery costs.
Specification
| Stainless Steel Plate | |
| Grade | 304/304L, 316/316L, 4003/AtlasCR12, 2205, 253MA |
| Thickness (mm) | 5.0 to 50.0 |
| Width (mm) | 1250 (grade 4003), 1500, 2000, 2500 |
| Length (mm) | 3000, 6000, Customer-specific cut-to-length |
| Finish | 2B (to 8mm), No.1 (HRAP) |
| Plasma profiles | To customer drawings |
Properties and Composition of 316 and 316L Steels
- Density: 0.799g/cubic centimeter
- Electrical resistivity: 74 microhm-centimetres (20 degrees Celsius)
- Specific Heat: 0.50 kilo Joules/kilogram-Kelvin (0–100 degrees Celsius)
- Thermal conductivity: 16.2 Watts/meter-Kelvin (100 degrees Celsius)
- Modulus of Elasticity (MPa): 193 x 103 in tension
- Melting Range: 2,500–2,550 degrees Fahrenheit (1,371–1,399 degrees Celsius)
Here is a breakdown of the percentages of various elements used to create type 316 and 316L steels:
| Element | Type 316 (%) | Type 316L (%) |
| Carbon | 0.08 max. | 0.03 max. |
| Manganese | 2.00 max. | 2.00 max. |
| Phosphorus | 0.045 max. | 0.045 max. |
| Sulfur | 0.03 max. | 0.03 max. |
| Silicon | 0.75 max. | 0.75 max. |
| Chromium | 16.00-18.00 | 16.00-18.00 |
| Nickel | 10.00-14.00 | 10.00-14.00 |
| Molybdenum | 2.00-3.00 | 2.00-3.00 |
| Nitrogen | 0.10 max. | 0.10 max. |
| Iron | Balance | Balance |
Contact us for your next stainless teardrop and diamond floor plate requirement.
